Features

■ LoRa Modem

■ 166dB maximum link budget

■ +30 dBm output power @433/470MHz band; +27 dBm output power @169 /868/915 MHz band

■ Programmable bit rate up to 300 kbps

■ High sensitivity: down to -136dBm

■ Low RX current of 13mA

■ FSK, GFSK, MSK, GMSK, LoRa and OOK modulation

■ Built-in bit synchronizer for clock recovery

■ Automatic RF Sense and CAD with ultra-fast AFC

■ Packet engine up to 256 bytes with CRC

■ Built-in temperature sensor and low battery indicator

■ SMD Package (35.4x18X3.85mm)
